• Class II luminaire
• IP66 tightness
• Impact resistance: IK10
• One-piece body in die-cast aluminium
• Injected polycarbonate bowl
• Mounting on a one-piece base with a Ø60mm mast top in die-cast
aluminium
• PAINTING :
• RAL powder coating of your choice
• Seaside option
• OPTICAL BLOCK :
– Lifetime L90B10 100000h
– Luminous efficacy up to 135 lm/W
– LED source flux from 1000 to 18000lm
– Optical lenses in PMMA
– Aluminium PCB up to 4 PCBs
– Optics: Road (R), Semi urban (SU), Urban (U), Square (P), Cycle path
(PCY), Pedestrian crossing, Architectural.
– Colour temperatures: 3000K, 2700K, 2200K, 1800K (4000K, on
request) – Optional 2 colour temperature coexistence*.
– ULR < 1%, ULR < 4% (in situ), CIE flux 3 code > 95%.
• BUILT-IN APPARATUS :
– Quarter-turn flange
– Optional antenna socket (Zhaga, Nema)
– Driver Lite prog, Driver Full prog (with DALI output on request),
Driver D4I and socket, optional
* Additional driver for mixed temperature option
• ELECTRICAL PROTECTION :
– 10kV lightning arrester
– Varistor on request
• All our components are ENEC certified
• STANDARDS :
– Embout recouvrant pour top 60mm
- Eligible for energy-saving certificate
- ENEC-certified components
- RoHS
- DEEE PRO member
- CE 1166
- ISO 9001
- ISO 14001
- Meets the requirements of the Decree of December 27, 2018 on the prevention, reduction and limitation of light pollution.
